Generator Automatic Voltage Regulator R150 AVR Circuit Diagram for Diesel Engine
Generator Automatic Voltage Regulator R150 AVR Circuit Diagram for Diesel Engine
Free Shipping to 63 countries (USA, Canada, Japan, Taiwan, etc). 5% discount applies to 1 pcs, 10% discount to 2 pcs!
Regular price
$65.00 USD
Regular price
Sale price
$65.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
The R150 automatic voltage regulator (AVR) is a compact, high-performance encapsulated unit. It incorporates the latest technology and efficient components to achieve a high degree of miniaturisation when applied to a 3-phase and 1-phase AC brushless generator, within its input and output limits. The unit offers excellent reliability.
|
Product Name
|
Generator AVR R150 AC Automatic Voltage Regulator Circuit Diagram
|
|
|
Sensing/Power input
|
Voltage
|
- Voltage: 240 VAC ± 10% for 1-phase, 380 V to 480 VAC ± 10% for 3-phase, 2-line sensing. The AVR senses the true average of the line-to-line waveform. Use the resistor (SMD) network for trouble-free sensing and control of sensed voltage/regulation.
|
|
Frequency
|
50/60 Hz jumper selectable
|
|
|
Output
|
Voltage
|
105 VDC at 240 VAC input
|
|
Current
|
6 A DC • 8 A for 30 sec. (when allowed by the field resistance)
|
|
|
Voltage setting
|
min ± 10% of rated voltage.
|
|
