Lixise Generator Controller Spare Parts Diesel Generator Auto Start Control Panel Module Lxc706
Lixise Generator Controller Spare Parts Diesel Generator Auto Start Control Panel Module Lxc706
Free Shipping to 63 countries (USA, Canada, Japan, Taiwan, etc). 5% discount applies to 1 pcs, 10% discount to 2 pcs!
Regular price
$68.00 USD
Regular price
Sale price
$68.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
LXC706 Lixise Controller
The Module LXC706 is an small Automatic Engine Control Modulelt selects 3 kinds of workingstate(Manual, Auto, Stop), can passpanel light touch buttons artificially start/stop genset, alsocan-through remote start signal input automatic starting generator,and can detect fault (lowoil pressure,high water temperature,emergency stop alarm, over speed) automatically disconnect fuelrelaysand stop electromagnet to electric suction close.Panel LEDindicator fault state, providereal andeffective fault alarm signal.
| Working Voltage | DC8. 0V to 35. 0V, Continuous Power Supply |
| Overall Consumption | standby mode: 12V:0.3W 24V:0.4W |
| working: 12V:1W 24V:1.1W | |
| AC voltage Input | Single phase 2 Wire 15V AC - 360 V AC (ph-N) |
| Alternator Frequency | 50/60Hz |
| Speed Sensor Voltage | 1V --24V(effective value) |
| Speed Sensor Frequency | maximum 10kHz |
| The maximum total run time | 99999.9 hours (After the decimal point is 1/10 hours,Six minutes |
| once changes) | |
| Start Relay Output | 1Amp DC28V B+ power supply |
| Fuel relay output | 1Amp DC28V B+ power supply |
| Shutdown relay output | 1Amp DC28V B+ power supply |
| Idle speed relay output | 1Amp DC28V B+ power supply |
| Programmable relay output | 1Amp DC28V B+ power supply |
| Switch input port | After B - effective |
| Overall Dimensions | 97mm x 78mm x 44mm |
| Panel Cutout | 78mm x 66mm |
| Working Conditions | Temperature:(-25~+70)C Relative humidity:(20~90)% |
| Storage Conditions | Temperature:(-30~+80)C |
| Protection Level | IP55:When waterproof rubber seal installed between the |
| controller and panel fascia | |
| IP42:When waterproof rubber seal is not installed between the | |
| controller and panel fascia | |
| Insulation Intensity | Object:input/output/power |
| Quote standard:IEC688-1992 | |
| Test way:AC1.5kV/1min leakage current:1mA |
