Alternator Voltage
|
0 to 300 V-AC (Ph-N) |
|
Alternator Frequency
|
0-100 Hz. |
|
DC Supply Range
|
9.0 to 33.0 V-DC |
|
Cranking Dropouts
|
survives 0 V for 100ms |
|
Typical Standby Current
|
100 mA-DC |
|
Maximum Operating Current
|
250 mA-DC (Relay outputs open) |
|
DC Outputs
|
10A @ 28V |
|
Charge Excitation
|
min 2 Watts |
|
Magnetic Pickup Input
|
0.5 – 30 V-AC. |
|
Magnetic Pickup Frequency
|
10 KHz max. |
|
Current Inputs
|
from CTs, .../5A. Max load 0.7VA per phase. |
|
Analog Input Range
|
0-5000 ohms. |
|
Serial Port
|
RS-232, 9600 bauds, no parity, 1 bit stop |
|
Operating Temp.
|
-40°C (-40°F) to 70°C (158°F) |
|
Storage Temp.
|
-55°C (-67°F) to 80°C (176°F) |
