HGM4020N series genset controllers integrate digitization, intelligentization and network technology which are used for genset automation and monitor control system of single unit to achieve automatic start/stop, data measurement, alarm protection and etc.
functions. It fit with LCD display, optional languages interface (Chinese, English, Spanish, Russian, Turkish, French, Portugal, and Polish), and it is reliable and easy to use.
1
/
of
6
Smartgen Genset Controller HGM4020N HGM4020NC HGM4020CAN HGM4020T With Maintenance Function
Smartgen Genset Controller HGM4020N HGM4020NC HGM4020CAN HGM4020T With Maintenance Function
Free Shipping to 63 countries (USA, Canada, Japan, Taiwan, etc). 5% discount applies to 1 pcs, 10% discount to 2 pcs!
Regular price
$132.00 USD
Regular price
Sale price
$132.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
HGM4020N
Advantage
* 132x64 LCD with backlight, selectable language interface (Chinese, English, Spanish, Russian, Turkish, French, Portugal, and Polish), push-button operation.
* Hard-screen acrylic material been used to protect screen with great wear-resisting and scratch-resisting functions.
* Silicone panel and pushbuttons can be used in extreme temperature environment.
* RS485 communication interface enable “Three remote functions” (remote control, remote measuring and remote communication)
* Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with voltage 120/240V and frequency
50/60Hz;
* Collects and shows 3-phase voltage, current, power parameter and frequency of generator or mains.
50/60Hz;
* Collects and shows 3-phase voltage, current, power parameter and frequency of generator or mains.
|
Function Item
|
Parameter
|
|
Display
|
LCD(132*64)
|
|
Language
|
Chinese&English&Others
|
|
Operation Panel
|
Silicon Rubber
|
|
Digital Input
|
5
|
|
Relay Output
|
6
|
|
Analogue Input
|
4
|
|
AC System
|
1P2W/2P3W/3P3W/3P4W
|
|
Alternator Voltage
|
(15-360)V(ph-N)
|
|
Alternator Frequency
|
50/60HZ
|
|
Monitor Interface
|
RS485
|
|
Programmable Interface
|
LINK/RS485
|
|
DC Supply
|
DC(8-35)V
|
|
Case Dimensions(mm)
|
135*110*44
|
