Smartgen HAT600N ATS Controller with RS485 Multi-function HAT600N
Smartgen HAT600N ATS Controller with RS485 Multi-function HAT600N
Free Shipping to 63 countries (USA, Canada, Japan, Taiwan, etc). 5% discount applies to 1 pcs, 10% discount to 2 pcs!
Regular price
$198.00 USD
Regular price
Sale price
$198.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
HAT600N
HAT600N series ATS controller is intelligent dual-supply module with programmable function, automatic measurement, LCD display, and digital communication. It combines digital intelligence and networking. Automatic measurement and control can reduce incorrect operation. It is an ideal option for ATS.
|
Items
|
Contents
|
||
|
Operating Voltage
|
DC 8.0V~35.0V, continuous power supply. HTS220/HWS560 power supply (without battery supply).
AC160V~280V (HAT600NB/HAT600NBI) during AC power L1N1/L2N2 supply. |
||
|
Power Consumption
|
<3W (Standby mode: ≤2W)
|
||
|
Rated Frequency
|
50/60Hz
|
||
|
Close / Open Trip Relay Output
|
16A AC250V Free Voltage relay output
|
|
|
|
Communication
|
RS485 isolated interface, ModBus Protocol
|
||
|
Dimensions
|
209mmx153mmx55mm
|
||
|
Panel Cutout
|
186mm x 141mm
|
||
|
Storage Condition
|
Temperature: (-25~+70)°C
|
||
|
Protection Rank
|
IP55: when waterproof gasket is installed between enclosure and control screen.
|
||
|
Insulation Strength
|
Apply AC2.2kV voltage between high voltage terminal and low voltage terminal
and the leakage current is not more than 3mA within 1min. |
||
|
Weight
|
0.8kg
|
||
