Smartgen HGM1790N Diesel Generator Controller Automatic Engine Auto Start Module Control Panel
Smartgen HGM1790N Diesel Generator Controller Automatic Engine Auto Start Module Control Panel
Free Shipping to 63 countries (USA, Canada, Japan, Taiwan, etc). 5% discount applies to 1 pcs, 10% discount to 2 pcs!
Regular price
$69.00 USD
Regular price
Sale price
$69.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
HGM1790N Genset Controller for Diesel Genset or Gasoline Genset
SUMMARY
HGM1790N Series generator controller integrating digital, intelligent and network techniques is used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming. The controller uses LCD display.
|
Item
|
Content
|
||
|
Operating Voltage
|
DC8. 0V to 35. 0V, Continuous Power Supply
|
||
|
Power Consumption
|
Standby, 12V-0.3W, 24V-0.4W
Working, 12V-1W, 24V-1.1W |
||
|
Alternator voltage Input
|
1P2L 15V AC ~ 360 V AC (ph-N)
|
||
|
Alternator Frequency
|
1V to 24V (active value)
|
||
|
Speed sensor Frequency
|
Max. 10kHz
|
||
|
Max. accumulative running time
|
99999.9 hours (it is 1/10 hour after decimal point, means changing/6 min.)
|
||
|
Start Relay Output
|
1Amp DC28V DC B+ power on to output
|
||
|
Fuel Relay Output
|
1Amp DC28V DC B+ power on to output
|
||
|
1Amp DC28V DC B+ power on to output
|
1Amp DC28V DC B+ power on to output
|
||
|
Idle Relay Output
|
1Amp DC28V DC B+ power on to output
|
||
|
Configured Relay Output
|
1Amp DC28V DC B+ power on to output
|
||
|
Switching value input port
|
Active when connected with B-
|
||
|
Overall dimensions
|
88mm x 76mm x 44mm
|
||
|
Panel cut off
|
78x66mm
|
||
|
Working conditions
|
Temperature, (-25~+70)ºC
Humidity, (20~90)% without condensation |
||
|
Storage Condition
|
Temperature, (-30~+80)ºC
|
||
|
Protective Level
|
IP55, when waterproof rubber ring added between controller and its panel.
IP42, when waterproof rubber ring not have between controller and its panel. |
||
|
Insulation Intensity
|
Object: among in input/output/power
Quote standard: IEC688-1992 Test way: AC1.5kV/1min 1mA leakage current |
||
|
Weight
|
0.15kg
|
